Fermi-11010 Architectural Expanded Metal Mesh Screens

Fermi-11010 Architectural Expanded Metal Mesh Screens offer a combination of strength and rigidity with a 45% front open area, allowing for excellent airflow, rated at 64%. Featuring a diamond pattern with a long way of 110 mm and a short way of 10 mm, along with a 10 mm strand width, this mesh is ideal for both decorative and functional applications. It is commonly used in facades, ventilation panels, sunscreens, and partitions, providing structural support while enhancing aesthetics. The open design facilitates natural light and air circulation, making it suitable for energy-efficient architectural solutions in both interior and exterior spaces.

Fermi-11010

Technical Specifications

architectural expanded metal mesh design drawing

Specifications of Fermi-11010 Architectural Expanded Metal Mesh Screens

Product Name	Fermi-11010-1	Fermi-11010-2	Fermi-11010-3
Material	Aluminum, Stainless Steel	Aluminum, Stainless Steel	Aluminum, Stainless Steel
LWD, mm (in)	110 (4.33)	110 (4.33)	110 (4.33)
SWD, mm (in)	10 (.394)	10 (.394)	10 (.394)
Strand Width, mm (in)	10 (.394)	10 (.394)	10 (.394)
Strand Thickness, mm (in)	1.5 (.059)	2 (.787)	3 (.118)
Front Open Area	45%	45%	45%
Air Open	65%	65%	65%
Max Width
Max Length
Approx. Weight, kg/m2 (lb/ft2)	2.3 (0.47)	3.1 (.635)	4.6 (.942)
