Fermi-503 Architectural Decorative Expanded Aluminum Mesh

Fermi-503 Architectural Decorative Expanded Aluminum Mesh features a diamond pattern with a long way of 50 mm and a short way of 3.5 mm, providing a front open area of 60% and an airflow rate of 75%. This lightweight yet durable mesh is ideal for both decorative and functional applications, such as metal facades, sunshades, and partitions. The high open area allows for excellent ventilation and natural light, making it suitable for energy-efficient designs. Its corrosion-resistant aluminum construction ensures longevity, while the customizable finishes offer enhanced aesthetic appeal for modern architectural projects.

Fermi-503

Technical Specifications

architectural expanded metal mesh design drawing

Specifications of Fermi-503 Architectural Decorative Expanded Aluminum Mesh

Product Name	Fermi-503
Material	Aluminum, Stainless Steel
LWD, mm (in)	50 (1.97)
SWD, mm (in)	3.5 (.138)
Strand Width, mm (in)
Strand Thickness, mm (in)	0.5 (.0197)
Front Open Area	60%
Air Open	75%
Max Width
Max Length
Approx. Weight, kg/m2 (lb/ft2)	0.52 (0.107)
