Fermi-107 Architectural Metal Screen Panels

Fermi-107 Architectural Metal Screen Panels feature a precise diamond pattern with a long way of 10 mm and a short way of 7 mm, offering a front open area of 42% and an airflow rate of 47%. These panels are designed for both functional and aesthetic purposes, making them ideal for applications such as facades, ventilation grilles, sunscreens, and privacy screens. The open area allows for effective air circulation while maintaining structural integrity. Made from durable materials, Fermi-107 Architectural Metal Screen Panels can be finished in various coatings to improve corrosion resistance and enhance their visual appeal, making them a versatile choice for modern architectural projects.

Fermi-107

Fermi-107B

Fermi-107

Technical Specifications

architectural expanded metal mesh design drawing

Specifications of Fermi-11010 Architectural Expanded Metal Mesh Screens

Product Name	Fermi-107-1	Fermi-107-2	Fermi-107-3
Material	Aluminum, Stainless Steel	Aluminum, Stainless Steel	Aluminum, Stainless Steel
LWD, mm (in)	10 (.394)	110 (4.33)	110 (4.33)
SWD, mm (in)	7 (.276)	10 (.394)	10 (.394)
Strand Width, mm (in)
Strand Thickness, mm (in)	1 (.039)	1.5 (.059)	2 (.079)
Front Open Area	42%	42%	42%
Air Open	47%	47%	47%
Max Width
Max Length
Approx. Weight, kg/m2 (lb/ft2), Aluminum	1.1 (.225)	1.7 (.348)	2.3 (.47)
Approx. Weight, kg/m2 (lb/ft2), Steel	3.2 (.655)	4.8 (.983)	6.6 (1.35)
